Cat5e Patch Cable

1.Cat5e UTP Patch Cable, with RJ45 8P8C Connector. 2.Rated Temperature:75Degree. 3.Stardard:UL444, TIA/EIA568B.2,ISO Patch Cord Cat5e.. 4.Conductor:Stranded bare copper. 5.AWG:24. 6.Insulation:HDPE. 7.Shield:Pe-Tape+Al foil+Pe-Tape. 8.Twisted pair:Four. 9.Drain wire: Solid Tinned copper. 10.Jacket:PVC. 11.Rip cord:Per request. Electrical Characteristic: 1>1.0-100.0MHz impedance(ohms):100+/-15. 2>1.0-350.0MHz delay skew (ns/100m):<=45. 3>Pair-to-Ground Capacitance Unbalance(pF/100m):<=330. 4>Max. Conductor DC Resistance 20 degree(ohms/km):93.8. 5.Resistance Unbalance(%):<=5. Application: 1.100 Base-T4. 2.100 Bsdr-TX. 3.100 VG-AnyLAN. 4.155Mbps ATM. 5.622Mbps ATM.
